FS3MW
31,43 $
FS3MW – Video Receiver.
Applications:
- FPV Drone Racing
- UAV Communication Systems
- Remote Vehicle Monitoring
- Wireless Video Transmission Systems
Key Features
- Audio Output: 58R3M(supported) , 58R3MW(without）
- Weight: 4.5g
- Dimensions: L28 x W23 x H3.5mm
- Power Supply: +3.3-5.0V
- Current Consumption: 220mA, Max
- Operating Temperature: -10~+65℃
- Storing Temperature: -30~+85°C
- Operating Humidity: 85% RH
- Receiving Frequency Range: 4900~5945MHz
- Voltage Standing Wave Ratio: 2:1
- Demodulation System: FM/PLL
- IF: 480MHz
- ANT.input impedance: 50Ω, Typ.
- LO Frequency Stabilization: ±100kHz
- LO Frequency Precision: ±100kHz
- LO Control: PLL
- Input LO Leak: -55dBm
- Receiving Sensitivity: -90dBm
- Input Level Range: -90dBm~+5dBm
- Video Output Impedance: 75Ω, Typ.
- Video Output Level: 1±0.2Vp-p
- Video Polarity: Negative
- Video Frequency Respone: ±5dB, Max. 50Hz~6MHz
- Differential Gain: ±5%, Max
- Differential Phase: ±5Deg., Max
- 3Db IF WIDEBAND: 16.5MHz
- S/N: 38dB, Min
- RSSI Output Voltage (-30dBm~90dBm): 0.7~2.2V
